Owner’s Manual 14
Reinstall the Refrigerator
Your dealer or Norcold authorized service center must do this procedure.
Make sure the combustion seal is not broken, is completely around the refrigerator mounting anges, and
is between the mounting anges and the wall of the enclosure. If the combustion seal is not complete,
exhaust fumes can be present in the living area of the vehicle. The breathing of exhaust fumes can cause
dizziness, nausea, and in extreme cases, death.
1. Push the refrigerator completely into the enclosure.
2. Install the screws in the upper and then the lower mounting anges on the front of the refrigerator.
3. Install the screws in the mounting ange at the rear of the refrigerator.
4. Put the plastic plugs into the mounting anges of the refrigerator.
To avoid possible propane gas leaks, always use two wrenches to loosen and tighten the gas supply line
connections.
5. Attach the gas supply line to the bulkhead tting of the refrigerator.
6. Open the valve at the propane gas tank(s).
Do not allow the leak checking solution to touch the electrical components. Many liquids are electrically
conductive and can cause electrical shorts and in some cases, re.
7. Examine the gas supply line for leaks.
8. Connect the DC wiring to the refrigerator:
- Connect the DC wires to the refrigerator.
- Install the DC fuse or connect the DC wiring to the battery or the converter.
9. Connect the black AC power cord to the receptacle.
Wiring Diagram and Pictorial
The parts in the wiring diagram are (See Art01871):
The parts in the wiring pictorial are (See Art01872):
AC heater .................................................................................................................................................................................................A
Light ......................................................................................................................................................................................................... B
Thermister ............................................................................................................................................................................................... C
Gas valve................................................................................................................................................................................................. D
Igniter....................................................................................................................................................................................................... E
Divider heater ...........................................................................................................................................................................................F
Temperature switch (optional) ................................................................................................................................................................. G
Fan (optional) .......................................................................................................................................................................................... H
Chassis ground..........................................................................................................................................................................................I
Door switch ...............................................................................................................................................................................................J
Temperature switch ................................................................................................................................................................................. K
Switched 12 VDC .....................................................................................................................................................................................1
Fused continuous 12VDC.........................................................................................................................................................................2
Communications ....................................................................................................................................................................................... 3
Display ground..........................................................................................................................................................................................4
Auxiliary ground (optional) ........................................................................................................................................................................ 5
Auxiliary +12 VDC (optional) ....................................................................................................................................................................6
Divider +12 VDC .......................................................................................................................................................................................7
Gas valve +12 VDC .................................................................................................................................................................................. 8
5 A Fuse DC ...........................................................................................................................................................................................F1
8A Fuse AC.............................................................................................................................................................................................F2
