10
Art02329
Door handle
Handle pocket
Hinge hole plug
8. Put the door onto the refrigerator and make sure that the gasket seals correctly.
9. Install and tighten the four (4) screws that attach the door hinge to the bottom of the
refrigerator.
Door mounting options:
This refrigerator is made to be installed in two ways (See Art02375). The “Flush Mount”
is with the refrigerator door inside of the mounting frame. The “Proud Mount” is with the
refrigerator door in front of the mounting frame.
Proud Mount
Flush Mount
Art02375
