Norcool Cu-900 - Technical Specifications and Dimensions; CU-350 Dimensions and Specs; CU-450 Dimensions and Specs; CU-900 Dimensions and Specs

Cu-350, Cu-450, Cu-900
3
CU-350
External dimensions w505 x d475 x h535 mm
Aperture w460 x h490 mm
Power Max. 305W
Lighting 14W tube
Defrost Automatic
Insulation Polyurethane foam, non-CFC
Coolant R134A
Net weight 27 kg
Power cable length 2.7m
Compressor Danfoss
Volt/Hz 220-240V AC 50Hz
Capacity Up to 5000 litres
Thermostat setting 3-12 °C (default 5 °C)
Ambient temperature 10-27 °C
Maximum wall thickness 330mm
Min. distance to ceiling
cold side 100mm
CU-450
External dimensions w590 x d510 x h690 mm
Recess w550 x h650 mm
Power Max 318W
Lighting 15W tube
Defrost Automatic
Insulation Polyurethane foam, non-CFC
Coolant R134A
Net weight 32 kg
Power cable length 2.4m
Compressor Danfoss
Volt/Hz 220-240V AC 50Hz
Capacity Up to 10,000 litres
Thermostat setting 3-12 °C (default 5 °C)
Ambient temperature 10-27 °C
Maximum wall thickness 230mm
Min. distance to ceiling
cold side 200mm
CU-900
External dimensions w590 x d510 x h690 mm
Recess w550 x h650 mm
Power Max 670W
Lighting 15W tube
Defrost To drain
Insulation: Polyurethane foam, non-CFC
Coolant R134A
Net weight 39 kg
Power cable length 2.4m
Compressor Danfoss
Volt/Hz 220-240V AC 50Hz
Capacity Up to 20,000 litres
Thermostat setting 3-12 °C (default 5 °C)
Ambient temperature 10-27 °C
Maximum wall thickness 230mm
Min. distance to ceiling
cold side 200mm
Dimensions: Cu-450 and Cu-900
'LPHQVLRQVDQGWHFKQLFDOVSHFLÀFDWLRQ
Dimensions: Cu-350
Figure 1
