Norcool Cu-900 - CU-450;CU-900 Installation Details; Appliance Operation and Maintenance; Replacing Light Tubes and Starters

Cu-350, Cu-450, Cu-900
5
1. 4 pcs. screws for front cover.
2. Front cover.
3. Screws for securing unit to wall.
4. Rubber seal for flange.
5. Broad foam tape.
6. Wooden seals
7. Insulation
8. D-seal
Cu-450, Cu-900
Using the appliance
Replacing light tubes and starters
CU-350
When replacing light tubes, remove
light cover. Push tube to one side
and extract from tube holder.
Always replace the starter when
replacing tubes. The starter is located
behind the front cover on the warm side.
CU-450/CU-900
Press cover down and pull out. Twist
tube a quarter turn and pull out.
Always replace the starter when
replacing tubes. The starter is located
by the side of the tube.
Figure 3
Figure 4
Figure 5
