2.1.1.2 Connection variants
trio SK 300E
SK 750 E
SK 52xE SK 53xE
vector mc
SK 700E SK 5xxE SK 200E SK 700E
(>22KW)
PC / laptop
NORD CON
Software
NORDAC Frequency inverter
Modules/options
Direct to terminals
(RS485)
SK CU1-STD
SK CU1-USS
Direct connection
to device
SK IC1-232/485
Part. No. 276970020
+
USB 5V Adapter
Part. No. 278910220
Connecting cable
Direct to system connector
Connection cable M12 socket–> wires
M12 So / wires
Part. No. 278910200
Connection cable M12 socket -> RJ12
RH12 / M12 So
Part. No. 278910230
Connection cable M12 socket -> SUB-D
M12 So / Sub-D So
Part. No. 278910210
ParameterBox
SK PAR-2H
Part. No. 278910100
