Nord Drivesystems SK CSX-3H User Manual

NORDAC Control and Parameter Boxes
8 Subject to technical alterations BU 0040 GB-1611
1.2 Delivery
Check the equipment immediately after delivery/unpacking for transport damage such as deformation or loose
parts.
If there is any damage, contact the carrier immediately and carry out a thorough assessment.
Important! This also applies even if the packaging is undamaged.
1.3 Scope of supply
Standard version:
The scope of supply includes one of the following devices,
Type Version IP protection class Part Number Comments
SK PAR-2E Installation IP 54 - front panel 278910110
SK PAR-2H Handheld IP 54 278910100 Incl. connection cable:
M12 plug connector, length approx. 3m
SK PAR-3E Installation IP 54 - front panel 275281414
SK PAR-3H Handheld IP 54,
IP 20 on plug
275281014 Incl. connection cable:
* RJ12-RJ12, length approx. 2m
* USB, length approx. 1m
SK CSX-3E Installation IP 54 - front panel 275281413
SK CSX-3H Handheld IP 54,
IP 20 on plug
275281013 Incl. connection cable:
* RJ12-RJ12, length approx. 2m
SK SSX-3A Handheld (wall-
mounting possible)
IP 54 275281513 Incl. M12 screw cable connector
SK POT1-1 Handheld (wall-
mounting possible)
IP 66 278910120 Incl. connection cable: length approx.
3m
Incl. M16 screw cable connector for SK
2xxE, SK 300E, SK 750E
Available accessories
: (For details see Section 2.5)
- Interface converter for connecting SK PAR-2x to a PC
- Various adapter plugs for connecting the parameter boxes to NORDAC frequency inverters
- Operating instructions as PDF file on CD ROM including NORD CON, (PC-based
parameterisation software)
- also available free of charge under www.nord.com
1.4 Certifications
1.4.1
European EMC Directive
If the control and parameter boxes are installed according to the
recommendations in this instruction manual, they meet all of the requirements of
the EMC directive according to the EMC product standard for motor-operated
systems EN 61800-3.
1.4.2 RoHS compliance
NORDAC control and parameter boxes are designed to be RoHS compliant
according to Directive 2002/95/EEC.
