3 ControlBoxes – SK POT1-1
BU 0040 GB-1611 Subject to technical alterations 57
3.2.2 Parameterisation
For the functions of the control box SK POT1-1, some parameters must be changed, according to the frequency
inverter and the options.
The most important of these are listed below. For further information, please refer to the manual for the relevant
frequency inverter.
Frequency inverter SK 2x0E
1)
SK 2x5E: SK 300E SK 5xxE SK
700E SK 750E
+ SK xU4-IOE + SK xU4-24V-
Function
Input (Parameter)
{Function}
Enable right DIN1 (P420[-01])
{01}
DIN5 (P480[-05])
{01}
DIN1 (P420[-01])
{01}
DIN2 (P421)
{01}
DIN1 (P420)
{01}
Enable left DIN2 (P420[-02])
{02}
DIN6 (P480[-06])
{02}
DIN2 (P420[-02])
{02}
DIN3 (P422)
{02}
DIN2 (P421)
{02}
Analog input AIN1 (P400[-01])
{01}
AIN1 (P400[-03])
{01}
AIN1 (P400[-07])
{01}
and
DIN3 (P420[-03])
{26}
AIN1 (P400)
{01}
AIN1 (P400)
{01}
Automatic start
(if required)
No input
(P428)
{1}
No input
(P428)
{1}
No input
(P428)
{1}
No input
(P428)
{1} or {2}
No input
(P428)
{1}
1)
For devices with an AS interface (SK 220E and SK 230E) analog input 1 is not present and therefore analog input 2 must be used.
Accordingly, parameter P400[-02] must be set to Function {01}.
3.2.3 Technical data
Name Value
Direction selector switch Left - OFF - Right
Potentiometer 0 … 100% (0 – 10V)
Ambient temperature 0°C … 40°C
Protection class IP66
Dimensions (L x W x D) (120 x 80 x 80)mm
Weight approx. 1.0 kg
Wall-mounting possible with 4 holes at the rear
Connection cable length approx. 3m
