2 Parameter Boxes – Display and control
BU 0040 GB-1611 Subject to technical alterations 25
2.2.2.2 ControlBox mode
Above firmware version 3.7 a further display mode (ControlBox) can be selected. If this mode is selected by the
user, the displays for the ControlBox (LED display of active parameter set and 4-digit "7-segment display") are
shown on the screen. This mode also enables access to new parameters of an inverter, even if these parameters
have not yet been implemented in the firmware of the ParameterBox. (Example: an inverter with current firmware
version is to be parameterised with a ParameterBox with an older firmware version)
1
O
O
_ _ _ _
ONLINE
I1 P1 Ready
NOTE
The digital frequency setpoint is factory set to 0Hz. To check whether the motor is working, a
frequency setpoint must be entered with the
or keys or a jog frequency via the respective
parameter >Jog frequency< (P113).
Settings should only be implemented by qualified personnel, strictly in accordance with the
warning and safety information.
ATTENTION: The motor may start immediately after pressing the START key
!
Operating display
(digit)
Parameter set display
via LED symbols,
similar to SimpleBox
(
see section 4.1.2
)
