8
4
8
52
3
3. If there is a shipping support attached to the
front of the Frame (1), remove the screws from
the shipping support, and discard the screws
and the shipping support.
Attach the Front Stabilizer (22) to the Frame (1)
with two M10 x 58mm Screws (74).
74
22
1
4. Attach the Water Bottle Holder (8) to the Seat
Carriage (4) with four M4 x 10mm Screws (52);
start all the Screws, and then tighten them.
4
5
5. Attach the Seat (5) to the Seat Carriage (4)
with four M8 x 16mm Screws (56); start all the
Screws, and then tighten them.
4
5
56
To Next Page
