8
4. Sujete el Montante Vertical (86) contra la Base
(94). Tenga cuidado de no pellizcar el Cable
del Montante Vertical (79). Introduzca tres
Pernos con Nylon 3/8" x 2 3/4" (7) con tres
Arandelas Estrella 3/8" (11) en el Montante
Vertical.
Apriete los Pernos con Nylon 3/8" x 2 3/4" (7)
hasta que las cabezas de estos entren en con�
tacto con el Montante Vertical (86); no apriete
todavía los Pernos con Nylon por completo.
94
4
86
7
11
79
3. Deslice la Cubierta del Montante Vertical (87)
hasta la parte inferior del Montante Vertical (86)
como se indica.
Con la ayuda de otra persona, sostenga el
Montante Vertical (86) cerca de la Base (94).
Vea el diagrama incluido. Ate firmemente la
atadura de cables del Montante Vertical (86) al
extremo del Cable del Montante Vertical (79).
Luego tire del otro extremo de la atadura hasta
que el Cable del Montante Vertical pase por
completo a través del Montante Vertical.
86
Atadura
de Cables
94
Oricio
87
86
79
79
Atadura
de
Cables
Oricio
3
