7092420 (Replaces 708452D)
Specifi cations & illustrations subject to change without notice or incurring obligations.
O’ Fallon, MO | Printed in U.S.A. (09/10)
Model Number JT5BD- 018K 024KA 030KA 036K 042K 048K 060K
Electrical
Data
Volts-Cycles-Phase (1) 208/230-60-1
Total Amps 9.9 11.8 14.6 15.7 17.5 19.7 26.4
Delay Fuse Max. (2) 20 25 30 30 35 40 50
Min. Circuit Ampacity 12.1 14.5 18.0 19.4 21.6 24.3 32.6
Component
Data
Coil
Area 15.17 15.17 22.88 25.42 22.88 25.42 25.42
Rows-FPI 1 - 18 1 - 18 1 - 20 1 - 20 2 - 16 2 - 16 2 - 16
Tube Dia 3/8” O.D.
Fan Motor
Type PSC
Amps 0.91 0.91 1.00 1.00 1.00 1.4 1.4
HP 1/8 1/8 1/4 1/4 1/4 1/4 1/4
Fan Blade
Dia-#
Blades
24” - 3
SCFM 2370 2370 3000 3000 3000 4000 4000
Compressor Data
RLA 8.3 10.8 13.4 15.3 19.2 19.8 25.3
LRA 40.3 56 68 87 112 105 146
Refrigerant suction line: Length/O.
Liquid Line: All Lengths - 3/8” O.D.
0-24 ft. 3/4” 3/4” 3/4” 3/4” 7/8” 7/8” 7/8”
25-39 ft. 3/4” 3/4” 3/4” 7/8” (3) 7/8” 7/8” 1-1/8” (4)
40-75 ft. 3/4” 3/4” 7/8” (3) 7/8” (3) 7/8” 1-1/8” (4) 1-1/8” (4)
R-22 Refrigerant charge (in ounces):
(Outdoor unit, Indoor Unit 15’ Line Set)
93 96 144 155 248 248 268
Approximate Weight (lbs.)
Net 166 171 190 204 252 276 285
Ship 175 180 200 215 265 290 300
(1) Operating Voltage Range: 198v min. - 253v max.
(2) HACR type circuit breakers may be used.
(3) Requires 7/8" to 3/4" reducer from line to unit.
(4) Requires 1 1/8" to 7/8" reducer from line to unit.
Table 18. Electrical Specifi cations & Physical Data
