Thissplitsystemcoolingunithasbeendesignedandbuilt
to provide many years of safe and dependable comfort,
providing it is properly installed and maintained. With
regular maintenance, this unit will operate satisfactorily
year after year. Abuse, improper use, and/or improper
maintenance can shorten the life of the appliance and
create unsafe hazards. A regular service and maintenance
schedule should be established to ensure efficient and
safe operation of the unit.
OPERATING INSTRUCTIONS
Thermostat stylesvary.Somemodels maynotinclude
theAUTOmodeandotherswillhavetheAUTOinplace
oftheHEATand COOL. Others mayincludeall three.
Please refer to the thermostat’s User Manual for detailed
programming instructions.
Thethermostatshouldbemountedabout5feetabovethe
floor on an inside wall and not on an outside wall or other
location where its operation may be adversely affected by
radiant heat from fireplaces, sunlight, or lighting fixtures,
and convective heat from warm air registers or electrical
appliances.
Cooling Operation
1. Setthethermostat’ssystemmodetoCOOLorAUTO
andchangethefanmodetoAUTO.SeeFigure1.
2. Set the temperature selector to the desired
temperaturelevel.Theoutdoorfan,compressor,and
blower motor will all cycle on and off to maintain the
indoor temperature at the desired cooling level.
NOTE: If the temperature level is re-adjusted, or the
system mode is reset, the fan and compressor in the
outdoor unit may not start immediately. A protective
timer circuit holds the compressor and the outdoor fan
offforapproximately5minutesfollowingaprevious
operation or the interruption of the main electrical
power.
Heating Operation
1. Setthethermostat’ssystemmodetoHEATorAUTO
andchangethefanmodetoAUTO.SeeFigure1.
2. Set the temperature selector to the desired
temperature level.The optional heating equipment
(furnace or electric heat) will cycle on & off to maintain
the indoor temperature at the desired heating level.
Operating the AC for Automatic Cooling &
Heating
1. SetthethermostatsystemmodetoAUTOandthe
thermostatfanmodetoAUTO.SeeFigure1.
2. Set the thermostat temperature selector to the
desired temperature level. The thermostat will
maintain the desired temperature level by switching
between either the outdoor cooling unit or the indoor
heating unit (furnace or electric heat) automatically.
Operating the Indoor Blower Continuously
Thecontinuousindoorbloweroperationistypicallyused
to circulate the indoor air to equalize a temperature
unbalance due to solar loads, increased occupancy loads,
or mechanical equipment operation. Set the thermostat
fan mode to ON (Figure 1). The indoor blower starts
immediately, and will run continually until the fan mode
isresettoAUTO.
NOTE:Thecontinuousindoorbloweroperationcanbe
obtained with the thermostat system mode set in any
position,includingOFF.
Turning the Air conditioner Off
Changethethermostat’ssystemmodetoOFFandthefan
modetoAUTO(SeeFigure1).NOTE:Thesystemwillnot
operate, regardless of the temperature selector setting.
