Operator’s manual
Optima 51 / M51 / M56 / M57T / 60T
46
Dynapôle Ludres/Fléville, 166 rue Ampère/BP 60093 - 54714 LUDRES - FRANCE - Tél.+33 (0)3 83 25 69 60 - Fax. +33 (0)3 83 26 12 85
11 3Oilltercartridgereplacement
First replacement should be carried out after 50 hours of service, then every 750 hours unless the lter
warning indicator is in the red zone. Then more frequently. (gure 2.29)
Procedure :
- unscrew the plug (gure 2.29 );
- remove the old cartridge and replace it, ref 113542. (gure 2.30);
- ll with oil (Figure 2.31)
- ret the plug and hand-tighten only.
gure 2.32
gure 2.30
gure 2.31
gure 2.29
plug
lter warning
indicator
The ller cap (g 2.32) ref 119539 should be changed after every 750 hours of work to prevent
blockage of the tank breather.
11 4Gearboxoilchange
gure 2.33
First change at 50 hours then every 500 hours (Figure 2.33)
Capacity of gearbox : 1.2 litres of oil, NOREMAT 80W90 (ref 102466)
Procedure :
- clean the area around the breather on top of dust and debris and
remove it.
- prepare a container capable of holding more than 1.2 litres of oil and
place under the gearbox drain plug.
- remove the drain plug from the bottom of the gearbox and allow to drain
for several minutes.
- replace the plug and tighten.
- replace the oil and check the level in the view-glass on the left hand side of the gearbox.
- replace the breather and wipe away any oil spills.
Operation and maintenance
