4
Do not place the flue terminal in an
indoor environment by means of add-
ing walls and ceiling (Do not enclose
using corrugated sheets, etc.)
Carbon monoxide poisoning or fire may
occur as a result.
Important Safety Information
-
2
(Continued)
If this unit will be installed in a beauty
salon or other location where hair
spray or aerosols will be used, locate
the unit in a separate area that is
supplied with fresh air from outdoors.
Prohibited
Be sure the gas/power
supplied matches the
gas on the rating plate.
For Natural Gas
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
Be sure
to do.
Be sure
to do.
(Continued)
Prohibited
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
Prohibited
Do not place or use a spray can
near
the water heater or the flue terminal.
Do not use hair spray or spray
detergent in the vicinity of the
heater.
Prohibited
Prohibited
Do not place outdoors
Rain may enter the unit
or the burner fire may be
blown by the wind, caus-
ing malfunction or fire as a
result.
Prohibited
Leave the proper clearance between
the water heater and nearby objects
(trees, timber, boxes with flammable
materials etc.).
Be sure
to do.
*
Indicates suggested clearances for maintenance.
Left side:
Min. 2" (50mm)
Right side:
Min. 2" (50mm)
Front:
Sug. 24" (600mm)
*
Sug. 3" (75mm)
from concetric
pipe*
Upper: Min.
12" (300mm)
Flue terminal
Do not place combustibles such as
laundry, newspapers, oils etc. near
the heater or the flue terminal.
Prohibited
Flue terminal
Do not use combustible chemicals
such as oil, gasoline, benzene etc. in
the near the heater or the flue terminal.
Prohibited
Carbon Monoxide Poisoning Hazard.
Do not install this water heater in a
recreation vehicle or on a boat.
Prohibited
WARNING
180,000
151,200
172,000
144,500
180,000 BTU
18,000 BTU
182
4.0
1.0 2.5"
10.5"
689
10.3b-2008
15
150
4.3b-2008
2
NR83-DVC
