6
ARM ATTACHMENT
(single-person use only)
1
2
1. Attachment connector
2. Zones
HIP ATTACHMENT
(single-person use only)
11
22
22
1. Attachment connectors
2. Zones
POWER SUPPLY
1
2
1. Barrel connector
2. Wall outlet plug
OPERATING INSTRUCTIONS >>
WARNING! BEFORE OPERATING THIS DEVICE: Read all warnings at the beginning of this manual. If you do not
understand these operating instructions, contact NormaTec at +1.617.658.5800.
SET UP THE SYSTEM
Step 1: Plug the power supply into an electrical outlet and then into the PULSE 2.0 device.
This device is equipped with a lithium ion battery. The battery automatically charges when the power supply is connected
to the PULSE 2.0 device and an electrical outlet.
Step 2: Connect the hose connector to the air outlet on the PULSE 2.0 device. The connector can only be inserted in the
correct orientation. Insert the connector firmly into the PULSE 2.0 device until you hear an audible “click.”
Step 3: Put the leg, arm, or hip attachments on. Find a comfortable position sitting, reclined, or lying down. If the
attachments have a zipper, be sure to zip up the attachments completely. Never try to use the system with the zipper partially
or totally unzipped—this could void your warranty. Only one set of attachments can be used with a single device. When using
more than one attachment, make sure they are both of the same type.
