18 TECHNICAL INFORMATION
Do not attempt to take apart the system.
The system has no user-serviceable parts. There are no user-replaceable fuses.
INTERNAL BATTERY INFORMATION
This device contains a rechargeable lithium ion battery. The battery will provide power for up to two
hours of continuous use. The battery is designed to allow use of the NormaTec PULSE without being
next to a power outlet. The battery is not designed to store a charge for long periods of time and will
slowly discharge from 100% to 0% over 24 hours. It takes approximately 6 hours to fully charge the
battery when the device is plugged in and not in use.
The rechargeable lithium ion battery is intended to be changed only by service personnel with the use
of a special service tool.
PULSE DIMENSIONS: 4” (width), 5” (depth), 9” (height); [10.2 cm (width), 12.7 cm (depth), 22.9 cm
(height)]
PULSE WEIGHT: 3.6 lbs [1.63 kg]
PULSE ELECTRICAL REQUIREMENT: 12V DC 1.2A
AC-DC ADAPTER
WARNING!
Only use the AC-DC Adapter Model Number 50-00048 provided with the system.
Using a dierent adapter may cause the system to not operate correctly.
INPUT: 100-240V .6-.8 A 50/60 Hz per NormaTec Model # 50-00048
OUTPUT: 12V DC Minimum 15 Watt per NormaTec Model # 50-00048
TEMPERATURE (OPERATING): +41° F to 104° F [+5° C to +40° C]
TEMPERATURE (STORAGE): -13° F to +158° F [-25° C to +70° C]
RELATIVE HUMIDITY (OPERATING): 15% to 93%, non-condensing
RELATIVE HUMIDITY (STORAGE): -25˚C without relative humidity control; +70˚C at relative humidity
up to 93%, non-condensing
ATMOSPHERIC PRESSURE (STORAGE AND TRANSPORTATION): 190hPa to 1060hPa
ATMOSPHERIC PRESSURE (OPERATING): 700hPa to 1060hPa
