31 | Operation
Humidifier Components
Figure 27: RH Humidifier Components
Steam Outle
t
Condensate Return
Fill Cup
Drain ValveDrain Canal
Fill Valve
Cylinder
Cylinder Plug
High Water Senso
r
Plug
On/Off/Drain Switc
h
Control Board
Power Relay
High Voltage
Terminal Block
Transformer
Control Terminal
Strip
Blowerpack
