Northern IP4MVFB - Mounting with a Gang Box

Network Bullet Camera·Quick Start Guide
19
19
9. Secure the camera to the junction box with screws.
10. Adjust the view angle. Refer to Step 6 in Section 2.3.1.
11. Adjust zoom and focus. Refer to Section 2.4
Junction Box
Safety Rope
Figure 2-8 Mounting with a Junction Box
2.2.3 Mounting with a Gang Box
Before you start:
The gang box is not included in package. You need to prepare one for
this mounting type.
Steps:
