Technical Specifications for XT Series Tractors
65
7. Technical Specifications for XT Series Tractors
7.1 Technical Specifications for 2W Drive XT Series Tractors
Type
Unit
20XT 22XT 25XT
Type —— Wheeled 4x4
Length (incl. rear
suspension
mm 2890/3030(excl. front counterweight)
Width
mm
1470
Outline size
Height(up to the top
of muffle)
mm 1907,or1933/1863,or1889
Wheelbase
mm
1577/1690
Front wheel mm
1100、1200、1300(adjustable)
Tread
Rear wheel mm
1150～1200、1300～1350(adjustable)
Ground clearance mm 320(tires 8.3-24),or 347.5(tires 9.5-240[gearbox,
down-side to ground]
Single sided brake m 2.5±0.2/2.6±0.2
Tuning circle radius
Non-single sided brake m 2.9±0.2/3.0±0.3
Structural mass kg 990/1040
Minimum used mass

kg 1100/1150
Front wheel kg
470
Mass distribution
Rear wheel kg
680
Front counterweight kg 54
Counterweight
Rear counterweight kg 124
Nominal traction power kN 4.3 4.5 4.8
PTO shaft power kW 13 14.5 16
Number of gears ——
8F+2R、8F+8R、16F+4R
Drive gears
2.06, 3.14
4.92, 6.79
9.52, 14.5
22.76, 31.37
Common
gear
Reverse
gear
2.71 12.53
Drive gears
2.06, 3.14
4.92, 6.79
9.52, 14.5
22.76, 31.37
Shuttle
gear
Reverse
gear
1.92, 2.92
4.59, 6.32
8.87, 13.51
21.2, 29.22
Drive gears
2.06, 3.14
4.92, 6.79
9.52, 14.5
22.76, 31.37
Clamping
drive gear
0.44, 0.67
1.06, 1.46
2.04, 3.11
4.88, 6.73
Theory speed
(calculated with the rear
wheels 9.5-24)
Clamping
gear
Reverse
gear
km/h
2.71 12.53
