16
NOVA Chuck Spanner
4.
Place
the
red
t
hread
protecto
r
washer
into
the
M6
threaded
hole
indicated
in
the
image.
Then
wind
the
M6
grub
sc
rew
in
position
and
tighten
with
3
mm
Hex
head
wrench
(provided)
which
pre
vents
the
chuck
from
loosening
from
the
lathe spindle.
