NOVATECH INSTRUMENTS 4 409C Manual Rev 1.12
3.7 Serial Commands. Commands are not case sensi-
tive and must end with any combination of Carriage Re-
turn (CR), Line Feed (LF) or CRLF. A response code is
returned after sending a command. See Table 1 for a list
of the response codes and Tables 2, 3 and 4 for a list of
the serial commands.
3.8 Query Command. The Q command returns the pre-
sent state of the 409C non-volatile parameters. See Ta-
bles 2 and 3 for a description of each of the parameters.
An example of the data returned by the Q command is as
follows:
q
Operating mode: 409C
F0=60.0000000 P0=0.00 V0=1.000
SWEF0=150.0000000
SWRSF0=1.0000000 SWFSF0=1.0000000
SWRST0=1.000 SWFST0=1.000
SWMD0=S SWENB0=D
F1=10.0000000 P1=0.00 V1=1.000
SWEF1=150.0000000
SWRSF1=1.0000000 SWFSF1=1.0000000
SWRST1=1.000 SWFST1=1.000
SWMD1=S SWENB1=D
F2=10.0000000 P2=0.00 V2=1.000
SWEF2=150.0000000
SWRSF2=1.0000000 SWFSF2=1.0000000
SWRST2=1.000 SWFST2=1.000
SWMD2=S SWENB2=D
F3=12.0000000 P3=0.00 V3=1.000
SWEF3=150.0000000
SWRSF3=1.0000000 SWFSF3=1.0000000
SWRST3=1.000 SWFST3=1.000
SWMD3=S SWENB3=D
Clock mode: I
FR 10.000000 MHz
FD 400.000000 MHz
Synthesis clock: 460.800000 MHz
VS=1 M=N I=A TSCALE=1
TRNG=00000 - 14249
TS input: Disabled
IOUD mode: Output
Firmware version: 1.6
OK
Error Code Meaning
OK Good Command Received
?0 Unrecognized Command
?1 Invalid Frequency
?4 Invalid Phase
?6 Invalid Parameter
?7 Invalid Amplitude
?8 Invalid Baud Rate
?A Invalid Amplitude
?C Invalid Channel Number
?D Invalid Dwell Time
?E Empty Row in Acve Range
?F Invalid Frequency
?M Invalid Parameter
?N Invalid Table Row Number
?P Invalid Phase
?R Table is Running
?T Invalid Table Command
?V Invalid Calibraon Value
?W Invalid Acve Row Range
?S Invalid when Sweep is Enabled
Table 1 Response and Error Codes
Example Response to ‘q’ Qommand
