26
Technical Specifi cations
UT is the A.C. mains voltage prior to application of the test level.
NOTE 1 At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies.
NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and
refl ection from structures, objects, and people.
A Field strengths from fi xed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile
radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
To assess the electromagnetic environment due to fi xed RF transmitters, an electromagnetic site survey should be
considered. If the measured fi eld strength in the location in which the ProCair Plus control unit is used exceeds the
applicable RF compliance level above, the ProCair Plus control unit should be observed to verify normal operation. If
abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the ProCair
Plus control unit.
B Over the frequency range 150 kHz to 80 MHz, fi eld strengths should be less than 3 V/m.
Immunity test IEC 60601 test level Compliance level Electromagnetic environment-guidance
Voltage Dips, short
interruptions and
voltage variations on
power supply input
lines IEC 61000-4-11
Voltage dips:
0 % U
T
; 0.5 cycle
0 % U
T
; 0.1 cycle
70 % U
T
; 25/30 cycles
Voltage dips
0 % U
T
; 0.5 cycle
0 % U
T
0.1 cycle
70 % U
T
; 25/30 cycles
Mains power quality should be that of a
typical home healthcare and professional
healthcare environment. If the user of the
ProCair Plus control unit requires continued
operation during power main interruptions, it
is recommended that the ProCair Plus control
unit be powered from an uninterruptible power
supply or a battery.
Voltage interruptions:
0 % U
T
; 250/300 cycle
Voltage interruptions:
0 % U
T
; 250/300 cycle
Power frequency
(50, 60 Hz) magnetic
fi eld IEC 61000-4-8
30 A/m
5 0 H z o r 6 0 Hz
30 A/m
50 Hz
Power frequency magnetic fi elds should be
a t l ev el s c har ac t eri stic of a t yp ic al l oc a ti on i n
a typical home healthcare and professional
healthcare environment.
Conducted RF
IEC 61000-4-6
3 Vrms:
0.15 MHz – 80 MHz
3 Vrms:
0.15 MHz – 80 MHz
Portable and mobile RF communications
e qu i pm e nt s h ou l d b e u se d n o c los er to a ny
part of the ProCair Plus control unit, including
cables, than the recommended separation
distance calculated from the equation
applicable to the frequency of the transmitter.
Recommended separation distance:
d = 1.2
d = 1.2 √P 80MHz to 800 MHz
d = 1.2 √P 800MHz to 2.5 GHz
Where P is the maximum output power rating
of the transmitter in watts (W) according to
the transmitter manufacturer and d is the
recommended separation distance in metres
(m).
Field strengths from fi xed RF transmitters, as
determined by an electromagnetic site survey,
A
should be less than the compliance level in
each frequency range.
B
Interference may occur in the vicinity of
equipment marked with the following symbol:
6 Vrms: in ISM and
amateur radio bands
between 0.15 MHz and
80 MHz
6 Vrms: in ISM and
amateur radio bands
between 0.15 MHz
and 80 MHz
80% AM at 1 kHz 80% AM at 1 kHz
Radiated RF
IEC 61000-4-3
10 V/m
80 MHz – 2.7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2.7 GHz
80 % AM at 1 kHz
