NV-DVR900 / NV-DVR1600 ver. 2.0 - User’s Manual
All rights reserved © NOVUS Security Sp. z o.o.
7
1.2. NV-DVR900 / NV-DVR900CD Technical Specification
Operation Mode: Quadroplex (simultaneous recording, live display, data playback and network connection)
Operation System : Linux
PTZ Functions: The ability to control PTZ cameras (Novus, Pelco, LG and others) utilizing Multiplexer without
the need to use additional keyboard, or through computer network utilizing Multi Viewer
software
Video Inputs: 9 x BNC, 1Vp-p, 75 Ω
Video Outputs: 1 x BNC –main monitor
1 x S-video - main monitor
1 x VGA - main monitor
1 x BNC - Call monitor
Resolution: 720 x 288, 360 x 288 (PAL), defined individually for each channel
Display Modes: 1, 4, 6, 8, 9, PiP, sequence, user defined, digital zoom, of selected image field x2, x3, x4
Compression: Wavelet (7 levels)
Recording Speed: from 1 frame/h up to 50 frames/s (100 frames/s for resolution 360 x 288), defined individually
for each channel
Display Speed: up to 25 frames per second for each channel (up to 225 frames per second for 9 channels split
screen)
Recording Modes: normal (continuous), schedule, alarm and/or motion detection event activation
Data Search: time/date or event
Motion Detection: grid 16x16, with adjustable sensitivity settings (specific for each camera)
Event List: up to 25 000 events (video loss detection, power loss, disk full, motion detection)
Alarm Inputs: 9 TTL inputs
Relays: 4 relay outputs (alarm) fully adjustable
Audio Inputs: 1 mono input cinch type, enhancing regulated in Multiplexer menu, sampling 8kHz
Audio Outputs: 1 mono output cinch type, signal level -5dB
Operation: front panel, remote control IR (included), computer network
Schedule: individual settings for each day of the week, individual settings for each camera, individual
settings for specific, exceptional days (holidays, etc.), different recording modes integration ,
CD writer: built in (version CD), external connected through USB port or IEEE1394 port (FireWire)
Image Backup: CD, HDD, USB devices, via computer network
External Ports: 1 x Ethernet - joint RJ-45, 10Mbit/sek,
1 x USB for external memory drives connection
1 x IEEE1394 for external memory drives connection
1 x RJ45 - for Speed Dome Cameras connection
2 x RJ45 - for system keyboard control
„Watch Dog” Function: hardware
Password Authorization: multilevel user accounts access and password protection, separate network passwords
Power Supply: 115-230 V AC, 55 W (±25%)
Dimensions: 432 x 88 x 430 mm
Weight: 8,2 kg (without HDD)
Operating Temperature: 0°C do +40°C
Humidity: 10-80% of relative humidity (without condensation)
