Step 5: Remove the cutting disc
completely.
Step 6: While the cutting disc is off,
clean the area from any dust and
debris using a soft brush.
Step 7: Insert a new cutting disc and
use the same wiggling motion to get the
new blade in place.
Step 8:
Important Note:
After positioning the blade, rotate it
slowly clockwise. It should move
smoothly without catching on the static
blade. If it does catch, refer to the static
blade adjustment section before
proceeding. Never secure the cutting
disc if it catches on the static blade, as
this will damage both components.
Step 9: Align the three holes of the cutting
disc with the coupling part behind it. Secure
the cutting disc by screwing the 3 bolts
removed in Step 3 back into place.
Reattach the safety screen and safety switch
panel removed in Step 2.
Secure the safety screen by screwing the 4
bolts removed in Step 1 back into place.
18
