Maintenance: blade replacement
Important Note:
Always ensure the machine is turned off and unplugged before
commencing any maintenance operations. Failure to do so could result in
serious damage to the machine or risk of injury.
Step 1: Undo and remove the 4x bolts
from the safety screen and the safety
switch panel.
Step 2: Remove the safety screen and
the safety switch panel.
Step 3: Undo and remove the 3 bolts
screwed into the cutting disc.
Step 4: Wiggle the cutting disc clockwise
and counterclockwise while pulling it
towards you to loosen it.
The blade should gradually lift away.
17
