6. Operation
- Do not change the controller's function switch settings during
operation.
Doing so may result in injury.
- Do not approach the machine after instantaneous power failure
has been recovered.
Doing so may result in injury if the machine starts abruptly.
- Be sure to check that the power supply specifications are correct.
Failure to do so may result in the controller becoming faulty.
- Be sure to provide an external emergency stop circuit so that
operation can be stopped with power supply terminated immediately.
- Be sure to conduct independent trial runs for the controller before
mounting the controller to the machine.
Failure to do so may result in injury.
- When an error occurs, be sure to eliminate the cause, ensure
safety, and reset the error before restarting operation.
Failure to do so may result in injury.
7. Maintenance And Inspection
- Do not disassemble, remodel, or repair the unit.
Doing so may result in electric shock, fire, or unit malfunction.
- The capacitor of the power line deteriorates through prolonged use.
We recommended that the capacitor be replaced every five years
to prevent secondary damage.
8. Disposal
- Be sure to handle the controller as industrial waste when
disposing of it.
1. Handing Precautions
- Do not touch components inside the controller.
Doing so may result in electric shock.
- Do not damage the cable by applying excessive load, placing
heavy objects on it, or clamping it.
Doing so may result in electric shock or fire.
DANGER
- Turn the power supply OFF before wiring, transporting and
inspecting the controller.
Failure to do so may result in electric shock.
- Provide an external safety circuit so that the entire system
functions safely even when the controller is faulty.
- Connect the grounding terminal of the controller.
Failure to do so may result in electric shock or malfunction.
- Do not expose the controller to water, corrosive atmosphere,
flammable gas, etc.
Doing so may result in fire or the controller may become faulty.
- Be sure to use the controller and the ABSOCODER sensor in the
environment designated by the general specifications in the manual.
Failure to do so may result in electric shock, fire, malfunction or unit
failure.
- Be sure to use the specified combination of the ABSOCODER
sensor, controller and sensor cable.
Failure to do so may result in fire or the controller may become faulty.
CAUTION
2. Storage
CAUTION
- Do not store the controller in a place exposed to water, or toxic
gas and liquid.
- Be sure to store the controller in a place within the designated
temperature and humidity range not exposed to direct sunlight.
- Be sure to consult NSD when the controller is stored for long
periods.
- Do not hold the cable or shaft of ABSOCODER sensor when
transporting. Doing so may result in injury or the controller may
become faulty.
CAUTION
3. Transport
Thank you very much for purchasing our product.
Before operating this product, be sure to carefully read this manual so that
you may fully understand the product, safety instructions and precautions.
- Please submit this manual to the operators actually involved in operation.
- Please keep this manual in a handy place.
Signal Words
Safety precautions in this guide are classified into DANGER and CAUTION.
Symbol
Meaning
DANGER
Incorrect handing may create a hazardous situation that
will result in moderate injury or physical damage.
Incorrect handing may create a hazardous situation that
will result in death or serious injury.
Instructions accompanied by a symbol may also result in serious
damage or injury. Be sure to observe all instruction accompanied by symbol.
Graphic Symbols
Symbol
Meaning
Indicates prohibited items.
Indicates items that must be performed / adhered to.
This product is not designated to be used under any situation affecting human
life. When considering the use of this product for special purposes, such as
for medical equipment, aerospace equipment, unclear power control systems,
traffic systems, etc., please consult NSD.
CAUTION
CAUTION
Application Limitation
4. Installation
- Do not step on the controller or place heavy objects on the controller.
Doing so may result in injury.
- Do not block the exhaust port or allow any foreign matter to enter
the controller.
Doing so may result in fire or unit failure.
- Be sure to secure the controller and ABSOCODER sensor with the
provided brackets.
Failure to do so may allow these to fall, resulting in malfunction or
injury.
- Be sure to secure the specified distance between the main body
and the control panel or other equipment.
Failure to do so may result in malfunction.
5. Wiring
-Be sure to secure the terminal block firmly.
Failure to do so may result in fire.
-Be sure to mount the terminal cover provided with the controller
before supplying power and starting operation after installation
and wiring has been completed.
Failure to do so may result in electric shock.
- Be sure to keep the sensor cable, control cable, and communication
cable at least 100 mm away from the main circuit and power line.
Failure to do so may result in injury or in malfunction.
- Be sure to connect all cables correctly.
Failure to do so may result in injury or the controller may become
faulty.
- Be sure to firmly connect the external I/O connectors and sensor
connectors.
Failure to do so may result in incorrect input and output or injury.
CAUTION
CAUTION
(Please read this safety guide carefully before operation)
GENERAL SAFETY RULES
DANGER
CAUTION
CAUTION
CAUTION
