NSD Varicam VS-5EX-1 - Switch Output Configuration and Run Mode

8-4.
Switch Output Setting
Set the key-switch to the SET position.
Setting Example
ON Position 125.5
OFF Position 234.5
Designate the Program No.
１
 PROGRAM
Designate the switch No.
１ ０７
       SWITCH
Designate the ON position value.
SET ON OFF
SENSOR
   POSITION
Press the [SET] key.
Program No. range:
Doesn’t apply to VS-5E Model.
VS-5ED

0
〜
7
VS-5EX

00
〜
15 or 00
〜
31
Switch No. range:
VS-5E

01
〜
24
VS-5ED

01
〜
24
VS-5EX

01
〜
40 or 01
〜
24
１
１１
１
２
２２
２
３
３３
３
５
５５
５
SET
SETSET
SET
┼
─
125.5 234.5
Switch output
４
４４
４
┼
─
１２５．
０
００
０.
..
.５
５５
５
┼
─
┼
─
- If the ON LED is not lit, press the [ON/OFF] key.
- A 0.5 degree unit setting is displayed with a decimal point.
- Designate the ON and OFF position values in order, beginning
from the smallest value.
SET
TEACH
CLEAR
INIT
RUN
●C-4●
