3. Accessory List
No. Part Name Quantity
1 E-Type Spray Nozzle 1
CAUTION
4. Connecting and Disconnecting the Handpiece from the Motor
4-1 Connecting
1) Insert the handpiece direct into the motor (Fig. 1). When connecting an optic handpiece, turn the handpiece
until it clicks and locks into position.
2) Confirm that the handpiece is securely connected to the motor.
4-2 Disconnecting
Hold the motor and the handpiece, then pull apart.
• Do not connect or disconnect the handpiece until the motor has completely stopped.
• Connect ONLY to E type motors (ISO 3964 (EN
ISO 3964)).
• Do not exceed the Max. Rotation Speed (Motor) shown in "9. Specifications".
Handpiece Motor
Fig. 1
