Caprice │ Installation and Operation Instructions - Parts List C 85-340
38
Table 12-1 Caprice Parts List:
Item
Part #
Models
Description
1
C85
C85-180
Boiler Only, C85
1
C220
C220-340
Boiler Only, C220
2
139
C85-340
Peep Hole Cover
3
497
C85-340
Coil, S-4 GPM , ½" NPT
4
13501
C85-340
Coil Plate Gasket
5
10152
C85-180
Smoke Hood, 6" Collar (c/w gasket strips)
5
10154
C220-340
Smoke Hood, 8" Collar (c/w gasket strips)
6
84787
C85-340
Fuel Smart HydroStat Model 3250 (Sensor only p/n = 85052)
7
12501
C85-340
Well (standard)
8
81342
C85-340
Tridicator
9
13701
C85-340
Relief Valve, 30 psi
10
82905
C85-340
Blocked Vent Switch, Natural Draft models only
11
134
C85-180
Jacket 305, Back (insulated)
11
150
C220-340
Jacket 306, Back (insulated)
12
133
C85-180
Jacket 305, Front (insulated)
12
149
C220-340
Jacket 306, Front (insulated)
13
132
C85-180
Jacket 305, Right Side (blank)
13
593
C220-340
Jacket 306, Right Side (blank)
14
141
C85-180
Jacket 305, Coil Side (insulated)
14
147
C220-340
Jacket 306, Coil Side (insulated)
15
135
C85-180
Jacket 305, Top Back, Large (insulated)
15
151
C220-340
Jacket 306, Top Back, Large (insulated)
16
137
C85-180
Jacket 305, Top Front , Small (insulated)
16
148
C220-340
Jacket 306, Top Front, Small (insulated)
17
503
C85-180
Flue Baffle, 14.5" Zig Zag (18/unit)
17
504
C220-340
Flue Baffle, 19.5" Zig Zag (22/unit)
18
10650
C85-180
Ceramic Fiber Board, 15.5" Dia. Disc
18
10661
C220-340
Ceramic Fiber Board, 17"x ¾" Dia. Disc
19
10618
C85-105
Burner, Riello F3, Natural Draft
19
10632
C220-340
Burner, Riello F10, Natural Draft
20
84024
C85-105
Blast Tube, Riello F3 Natural Draft
20
84654
C220-340
Blast Tube, Riello F10 Natural Draft
21
10630
C125-180
Burner & Blast Tube, Riello F5, Natural Draft
21
81032
C95-125
Burner & Blast Tube, Beckett, NYC601, Natural Draft
21
81032
C150-180
Burner & Blast Tube, Beckett, NYC602, Natural Draft
21
81122
C95-150
Burner & Blast Tube, Riello BF5, Direct Vent
21
81662
C95-105
Burner & Blast Tube, Beckett, NYC804, Direct Vent
22
81112
C95-150
6"- 3" Ported Adapter
23
81098
C95-150
3" Insulated Flex to Pipe Adapter
24
81138
C95-150
3" Flex, 10 '
25
81586
C95-105
4" to 3" Increaser (Beckett only)
26
81625
C95-150
Hose Clamps, 3"
27
81522-1
C95-150
Direct Vent Terminal, 8” Wall
28
81109
C95-150
Insulated Flex, 5 '
28
81097
C95-150
Insulated Flex, 10 '
28
81110
C95-150
Insulated Flex, 15 '
28
81111
C95-150
Insulated Flex, 20 '
29
81522-2
C95-150
Extended Direct Vent Terminal, 20" Wall (optional)
30
81453
C95-150
Silicone, High Temperature, Nu Flex 302, Red (83ml)
31
81847
C95-150
3" Direct Vent 90 Degree Elbow (optional)
32
81633
C95-150
3" x 20 ' Flex Aluminum (optional)
33
795
C85-305
SideShot Power Venter, SS1C (certified w/ Riello Natural Draft models only)
