NTI ENVIROMUX Series Wiring Instruction

4
You will need to Disable the
Relay Interlock (under
Administration-System- Other
Options) in order to associate
the same output relay with two
sensors.
Otherwise, you can wire to
have a second output relay
break the circuit when the
keypad tamper switch closes.
If you remove the default
checkmark from Auto
acknowledge, then even if
someone tries to override the
keypad control over the strike,
the strike will not deactivate
until the alert is acknowledged
by the administrator.
Example of possible sensor configuration settings for
Tamper connection at Digital Input

NTI ENVIROMUX Series Specifications

General

Product Type	Environmental Monitoring System
Temperature Range	-40°C to 85°C
Power Supply	12V DC or 24V AC
Network Interface	Ethernet 10/100 Mbps
Alarm Notifications	Email, SNMP
Sensor Types Supported	Temperature, Humidity, Water, Airflow
Power	12V DC or 24V AC
Operating Temperature	-40°C to 85°C
Mounting	Wall or Rack Mount
Communication Interfaces	Ethernet
Data Logging	Yes
Compliance	CE, RoHS
