Installation and Operation Instructions Matrix
46
Setting Matrix Fan Control
Just as the Matrix Boiler Controller controls all of the operation and safety functions of the boiler, the Matrix Fan
Controller controls all of the operational functions related to air handling and hot water dispatching. The fan
controller controls the forced air modulation, ventilation, as well as priority of domestic hot water and secondary
heating systems. See Table 13-5 for a description of the fan control settings.
Table 13-5 Matrix Fan Control Programming
Menu Item
Settable
Range
Default
Description
Main
Sub
RUN
When Run is displayed, controller is in ‘Prog’ mode. Arrow up or down to scroll
through menus
HRV
OFF / ON
ON
HRV Mode – Always off unless call for high ventilation (DH)
HRV Mode – Continuous Ventilation. HRV will exchange air at low ventilation
rate during a call for forced air heat (W1 or W2) or continuous circulation (G).
Will increase to high ventilation rate with a high ventilation call (24vac @ DH)
HEA
PF1- PF3
PF1
Heat Profile 1 400 to 1000CFM; 50,000 Btu/h max.
Heat Profile 2 400 to 1100CFM; 77,000 Btu/h max.
Heat Profile 3 400 to 1200CFM; 105,000 Btu/h max.
Y1
40-Y2
80
Stage 1 AC/HP Flow x 10 = CFM, settable from 400 up to Y2 (1600 max).
Y2
Y1-160
120
Stage 2 AC/HP Flow x 10 = CFM, settable from Y1 (400 min) up to 1600.
FAN
40-160
40
Fan circulation rate (G) x 10 = CFM, settable from 400 to 1600.
BAL
SCL
30-100
60
HRV Balancing – (see HRV section for more details)
ECL
30-100
60
SCH
30-100
60
ECH
30-100
60
SOL
30-100
100
EOL
30-100
100
SOH
30-100
100
EOH
30-100
100
H2O
100-160
125
Set point for desired DHW temperature in degrees Fahrenheit.
rAd
1 or 2
2
Determines the anticipated supply plenum size. For units with the 20x16” Supply
Plenum, set to 1. For units with the 22.5x18.5” Supply Plenum, set to 2.
