Table 19-1 Parts List:
Item
Part #
Models
Description
1
82657
Lx150, M100(V), Ti100-150
Premix Burner 135.8
2
82761
Lx150–500, M100(V), Ti100-
400, Ts80
Premix Burner Gasket, Lx/M/Ti/Ts (80-500)
3
82771
Lx150-200, M100(V), Ti100-
200, Ts80
Extended Air Tube Lx/M/Ti/Ts (80-200)
4
82766
Lx150–500, M100(V), Ti100-
150, Ti400, Ts80, Tx51-151,
Tx151C
Blower Gasket Lx/M/Ti/Ts/Tx (51-500)
5
82052
Lx150, M100(V), Tft60-110,
Ti100-150, Ts80
EBM Blower RG130
6
82054-2 (84299)
Lx150-300, M100(V), T150-
200, Tft60-250, Ti100-200,
Ts80, Tx200, Tx200C
Venturi Gasket, Cork
7
82054-1 (84297)
Lx150-200, M100(V), Ti150-
200
Venturi 001
8
82650
Lx150-200, M100(V), Tft110,
Ti150-200
Gas Valve Orifice 5.2mm, LP
9
82054 (83204)
Lx150–300, M100(V), T150-
200, Tft60-250, Ti100-200,
Ts80
Gas Valve VK8115V1341B (Valve Only)
10
82708 (82708-1)
M100(V), Ti100-400
Igniter Hot Surface, Norton 601, SS Shield (Includes
Disconnects)
11a
82768
M100(V), Ti100-400
Igniter Gasket, Hot Surface, Ti/M
12
82600 (82600-1)
Lx150-300, M100(V), Tft60-
250, Ti100-200, Ts80
Gas Valve Regulator Vent Upgrade Kit c/w Clamp
(Includes p/n: 83134)
13
83883
M100(V), Lx150-300, Tft60-
250, Ti100-200, Ts80
Gas Valve Inlet O-Ring Gasket
14
82065
Lx150-300, M100(V), T150-
200, Ti100-200, Ts80,
Tx200, Tx200C
Gas Valve Adapter 1/2" NPT Elbow
15
82671
M100(V), Ti100-200
(see bullets)
Thermister, 1/8" BSP (see bullets)
 All non-ASME M100(V) & Ti100-150 models
manufactured before 3/20/2008
 All Ti200 models manufactured before 2/1/2008
16
83223-1 (83218)
Lx150-400, M100(V), Ti100-
200, Ts80 (see bullets)
Low Water Pressure Switch 1/4" NPT (see bullets)
 All M100(V) models sold in US
 All Lx150-400 models
 All ASME stamped Ti100-150 models
 All M100(V) & Ti100-150 models manufactured after
3/20/2008
 All Ti200 models manufactured after 2/1/2008
16
83223
M100(V), Ti100-200 (see
bullets)
Low Water Pressure Switch 1/8" BSP (see bullets)
 All non-ASME M100(V) & Ti100-150 models
manufactured before 3/20/2008
 All Ti200 models manufactured before 2/1/2008
