NTI Matrix - Page 63

Matrix Installation and Operation Instructions
63
Item
Part #
Models
Description
17
83462
Lx150-200, M100(V), Ti100-
200, Ts80
(see bullets)
Street Tee, Brass, 1/4" Lx150-200 (see bullets)
 All M100(V) models sold in US
 All Lx150-200 models
 All ASME stamped Ti100-150 models
 All M100(V) & Ti100-150 models manufactured after
3/20/2008
 All Ti200 models manufactured after 2/1/2008
18
82228
Combi (T/Ti), M100(V)
Tempering Valve # AM101-US-1
19
82539
Lx150-800, M100(V), Ti100-
400, Ts80
Auto Air Vent, 1/8" NPT
20
82660 (82660-1)
M100(V), Ti100-200
Stack Limit 1/4BSP, 190F, Dif=30 (c/w Disconnects)
21
82765
Lx150-200, M100(V), Ti100-
200, Ts80
Composite Flue Outlet Gasket Lx150-200
22
82763
Lx150-200, M100(V), Ti100-
200, Ts80
Composite Flue Box
23
82764
Lx150-200, M100(V), T150-
200, Ti100-200, Ts80
Trinity Flue Box To Heat Exchanger Gasket
24
83507
M100(V)
Flow Meter [M100(V) manufactured after 2/21/2008]
25
82659
M100(V), Ti100-200 (see
bullets)
Manifold Limit 1/8" BSP (see bullets)
 All non-ASME M100(V) & Ti100-150 models
manufactured before 3/20/2008
 All Ti200 models manufactured before 2/1/2008
25
82992 (82992-1)
M100(V), Ti100-400 (see
bullets)
Manifold Limit 1/4" NPT c/w Disconnects (see bullets)
 All M100(V) models sold in US
 All Ti400 models
 All ASME stamped Ti100-150 models
 All M100(V) & Ti100-150 models manufactured after
3/20/2008
 All Ti200 models manufactured after 2/1/2008
26
83012
Lx150 (US), M100(V) (US),
Ti100-150 (US)
Heat Exchanger ASME, Lx/Ti100-150 (Not Lx150E),
US Only
26
82596
M100(V) (CAN), Ti100-150
(CAN)
Heat Exchanger Kit Ti100-150 (Kit includes p/n:
83395)
27
83042
Lx150-200, M100(V), Ti100-
200, Ts80
Y Drain Fitting 5/8" White
28
82011
Combi (T/Ti), M100(V)
Heat Exchanger, Brazed Plate LA1430
29
82160
Combi (T/Ti), M100(V)
3 Way Valve VU54S2016B, 3/4"
30
82913 (83510)
M100(V), Tft60-399, Ti100-
400, Tx51-200, Tx151C,
Tx200C
Condensate Trap
31
83112 (83112-1)
Lx150-800, M100(V), T150-
200, Ti100-400, Ts80
Trinity Divider Plate Insulation Kit c/w Screws &
Washers
32
82770
Lx150-500, M100(V), Ti100-
400, Ts80
Burner Door Viton Gasket (Not Lx600-800)
34
82767-1
M100(V), Ti100-200, Ts80
Cast Aluminum Burner Door Kit – NOT FOR USE W/
Lx300-400 OR Ti400
35
82973
M100(V)
3 Way Actuator VU844A1003B
