Figure 9-9 Lx500-600 Models
Flue Gas Sampling Using Test Port
Figure 9-10 Lx700-800 Models
Flue Gas Sampling Using Test Port
Test Port
Combustion
Analyzer
FLUE GAS TEST PORT PLUG - Remove test
port plug to perform flue gas analysis. Re-install
plug once sampling completed to prevent flue gas
leakage during appliance operation. Failure to
comply with these instructions will result in serious
injury or death.
Combustion
Analyzer
Test Port
FLUE GAS TEST PORT PLUG
Remove
test port plug to perform
flue gas analysis. Re-install
plug
once sampling completed to prevent
flue gas leakage during appliance
operation. Failure to comply with
these instructions will result in
serious injury or death.
