Lx Series Installation and Operation Instructions │Trinity Lx
53
13.0 PARTS LIST
For a list of parts that corresponds to the item numbers in the bubbles, refer to Table 13-1. Note that that some
item numbers may appear more than once in the parts list depending on which model number is being referenced.
Building Owners - Replacement parts are available from your stocking wholesaler. Contact your local Installer
or Wholesaler for assistance with parts.
Wholesalers - Contact NY Thermal Inc. directly when ordering replacement parts, 1-506-657-6000.
Installers - Contact NY Thermal Inc. directly if technical assistance required, 1-800-688-2575.
Residential Models (Lx150-400)
Figure 13-1 Lx150-200 Models
Cabinet, Vent and Air-Intake Parts
76
44
41
43
45
40
38
39
50
49
48
46
47
72
73
75
66
53
55
64
37
To Next Page
