Trinity Lx │Installation and Operation Instructions Lx Series
62
Item Part # Models Description
30 83907 300, 400 Condensate Drain Tube (Lx300-400)
30 84313 500, 600 Condensate Drain Tube (Lx500-600)
30 83996 700, 800 Condensate Drain Tube (Lx700-800)
31 83112 All Models Trinity Divider Plate Insulation c/w Washer & Screw (Lx Series)
32 82770 150–500 Burner Door Viton Gasket (Lx150-500)
32 84136 600–800 Burner Door Viton Gasket (Lx600-800)
33 83808 150, 150E, 200, 500 Burner Door Ceramic Disc (Lx150-200,500)
33 83950 300, 400 Burner Door Ceramic Disc (Lx300-400)
33 84137 600–800 Burner Door Ceramic Disc (Lx600-800)
34 83885 150, 150E, 200, 500 Cast Alum Burner Door (Lx150-200,500)
34 83949 300, 400 Cast Alum Burner Door (Lx300-400)
34 84135 600–800 Cast Alum Burner Door (Lx600-800)
35 83934 300, 400 Nipple, 1/4" x 6", Brass 113-B6 (Lx300-400)
36 82762 150–500 Flame Rod (Lx150-500)
36 84155 600–800 Flame Rod (Lx600-800)
37 82099 150, 150E, 200, 300 1-1/2" MJ Coupling (Lx150-300)
37 83951 400 2" Gear Clamp Assembly (Lx400)
38 83425 150, 150E, 200 Elbow, Street 90, PVC Sys 15,1-1/2" (Lx150-200)
39 83426-1 150 (US) 1-1/2" PVC Pipe, Sys 15, 1.75" Long (Lx150 US)
39 83426-2 150E, 200 1-1/2" PVC Pipe, Sys 15, 4.5" Long (Lx150E-200)
39(a) 84208 300 1-1/2" Air Metering Assembly (Lx300)
39(b) 84209 300 2” PVC Air Inlet Assembly (Lx300)
39 83952 400 Air Inlet Assembly (Lx400)
40 83425-1 150, 150E, 200 Air Metering Elbow (Lx150-200)
41 83712 150, 150E, 200 Flue Outlet Adapter (Trinity Lx 3” PVC), c/w plug (Lx150-200)
41 83213 300, 400 Flue Outlet Adapter (Lx300-600)
41 84387 500, 600 Flue Outlet Adapter c/w Tabs (Lx500-600)
41 84052 700, 800 Flue Outlet Adapter (Lx700-800)
42 82882 300, 400 Coupling, Rubber , 4", Fernco (Lx300-400)
42 84051 500–800 Air Inlet Adapter SS (Lx Commercial)
43 83477 150, 150E, 200 Bushing, PVC Sch. 40, 3"x1.5" (Lx150-200)
44 83712-1 150, 150E, 200 3/8" Stainless Steel Plug (Lx150-200)
44 84054 300–800 Exhaust Test Plug (Lx300-800)
45 83873 150, 150E, 200 TiS Wall Mount Bracket 2 (Lx150-200)
45 83953 300, 400 Wall Mounting Clip (Lx300-400)
46 83505 150, 150E, 200, 300 Grommet, Vinyl, 1/2" IPS (Lx150-300)
46 83923 400 Grommet, Vinyl, 3/4" IPS (Lx400)
46 83506 600–800 Grommet, Vinyl, 1" IPS (1030) (Lx600-800)
47 83506 150, 150E, 200 Grommet, Vinyl, 1-3/8" OD
47 83924 300, 400 Grommet, Vinyl, 2" OD (Lx300-400)
47 84097 500–800 Grommet, Vinyl, 2 1/2" IPS (3125) (Lx Commercial)
48 83874 150, 150E, 200 TiS Air Switch Support Clip II (Lx150-200)
48 83954 300, 400 Air Switch Bracket (Lx300-400)
48 84139 600–800 Air Switch Bracket (Lx600-800)
49 82662 All Models Air Switch Huba 604.E021180 set @ .15" w.c. (Lx Series)
50 83875 150, 150E, 200 TiS Wall Stand-Off - Bottom (Lx150-200)
50 83955 300, 400 Wall Mounting Support, Bottom (Lx300-400)
51 83508 All Models Display Molding (Lx Series)
52 83592 All Models Trinity Touch Screen Display (Lx Series)
53 83876 150, 150E, 200 Electrical J-box Cover R1, Left (Lx100-200)
