Trinity │Installation and Operation Instructions Tft Series
18
Table 4-7 Optional Vent Termination Kits
Description
Vent
Size
Supplier P/N
Figure
Vent Material
Compatibility
Vent Option
Roof
Wall
IPEX Low Profile (Wall)
7
2”
196984 (NTI P/N 85062)
4-4(b), 4-6(c)
PVC/CPVC
7


3”
196985 (NTI P/N 84357)
4”
196986 (NTI P/N 84358)
IPEX Concentric
(Wall/Roof)
5,6,7,8
2”
196125
4-4(c), 4-5(b),
4-6(b), 4-7(b)
PVC/CPVC
7


3”
196116 (NTI P/N 82666),
197117
4”
196021 (NTI P/N 84355),
197021
PolyPro® Concentric
(Wall)
2-4”
2PPS-HK, 3PPS-HK,
4PPS-HK
4-4(d), 4-6(d)
PolyPro®
Polypropylene


PolyPro® Concentric
(Roof)
2-4”
2PPS-VK, 3PPS-VK,
4PPS-VK
4-5(c), 4-7(c)


InnoFlue® Flush Mount
(Wall)
2-3”
ISLPT0202, ISLPT0303
InnoFlue®
Polypropylene


InnoFlue® Concentric
(Wall)
9
2-4”
(ICWT242 & ICTC0224),
(ICWT352 & ICTC0335),
(ICWTS462 & ICTC0446)
4-4(d), 4-6(d)
InnoFlue® Concentric
(Roof)
9
2-4”
(ICRT2439 & ICTC0224),
(ICRT3539 & ICTC0335),
(ICRT4679 & ICTC0446)
4-5(c), 4-7(c)


Z-DENS® Horizontal Kit
Low Profile (Wall)
4”
2ZDHKLP4
4-4(b), 4-6(c)
Z-DENS®
Polypropylene


Z-DENS® Concentric
(Wall)
2-4”
2ZDHK2, 2ZDHK3,
2ZDHK4
4-4(d), 4-6(d)
Z-DENS® Concentric
(Roof)
2-4”
2ZDVK2, 2ZDVK3,
2ZDVK4
4-5(c), 4-7(c)


Notes:
1
Instructions included with termination kits contain detailed assembly and installation instructions.
2
All factory termination kits are ULC S636 approved.
3
Clearance requirements in this manual supersede those of the instructions included with the vent terminal.
4
Piping MUST be secured to the vent terminal during installation.
5
IPEX Concentric Terminal MUST be cemented together and to the vent pipes during installation.
6
Vent Screens provided with boiler may be used with the IPEX Concentric Vent Kits; otherwise use IPEX vent screens
(2” vent screen P/N 196050; 3" vent screen P/N 196051; 4" vent screen P/N 196052 – each sold separately).
7
IPEX Low Profile and Concentric kits (excluding P/N’s 197117 & 197021) are constructed out of ULC S636 approved
PVC; check with your local authority for the acceptance of PVC as a venting material prior to use.
8
IPEX Concentric kits can be shortened to fit the requirements of the installation; see instructions included with the kit for
more details.
9
Centrotherm Concentric termination kits must use the applicable “Twin pipe to concentric adapter,” part number
ICTC0224, ICTC0335 or ICTC0446.
10
2” Vent Termination Kits may only be used with models Tft60-154.
11
3” Vent Termination Kits may only be used with models Tft60-285.
12
4” Vent Termination Kits may only be used with models Tft340-399.
PVC In Canada - Authorities in some jurisdictions may not allow the use of any PVC
venting materials with condensing boilers; check with the local safety inspector to verify
compliance prior to installing a PVC Concentric Vent Kit with a Trinity Tft.
