Tft Series Installation and Operation Instructions │Trinity
19
Sidewall Venting Options – Direct Vent Installation
Figure 4-4(a)
Figure 4-4(b)
Two-pipe Termination (Sidewall)
Low Profile Termination (Sidewall)
Figure 4-4(c)
Figure 4-4(d)
IPEX Concentric Termination (Sidewall)
PolyPro / InnoFlue Concentric Termination (Sidewall)
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Exhaust
Inlet
