Trinity │Installation and Operation Instructions Tft Series
42
Near Boiler Piping (Tft201-285)
Figure 10-2(a) Supply/Return Bottom
Figure 10-2(b) Supply/Return Top

Boiler Outlet and Inlet water connection location varies between
models; reference the applicable figure for correct location.
Figure 10-2(c) Supply Top / Return Bottom
Figure 10-2(d) Supply Bottom / Return Top
Outlet
Inlet
Auto Air-Vent
(factory Supplied)
Pressure Relief Valve
(factory Supplied)
Pressure Relief Valve
(alt. location – check
local installation codes)
Press. & Temp. Gauge
(factory Supplied)
Outlet
Inlet
Auto Air-Vent
(factory Supplied)
Pressure Relief Valve
(factory Supplied)
Pressure Relief Valve
(alt. location – check
local installation codes)
Press. & Temp. Gauge
(factory Supplied)
Inlet
Outlet
Auto Air-Vent
(factory Supplied)
Pressure Relief Valve
(factory Supplied)
Pressure Relief Valve
(alt. location – check
local installation codes)
Press. & Temp. Gauge
(factory Supplied)
Outlet
Inlet
Auto Air-Vent
(factory Supplied)
Pressure Relief Valve
(factory Supplied)
Pressure Relief Valve
(alt. location – check
local installation codes)
Press. & Temp. Gauge
(factory Supplied)
