Trinity │Installation and Operation Instructions Tft Series
20
Roof Venting Options – Direct Vent Installation
Figure 4-5(a)
Figure 4-5(b)
Two-pipe Termination (Roof)
IPEX Concentric Termination (Roof)
Figure 4-5(c)
Figure 4-5(d)
PolyPro / InnoFlue Concentric Termination (Roof)
Two-pipe Termination (Roof-exhaust / Sidewall-inlet)
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Exhaust
Inlet
Exhaust
Inlet
Location of exhaust and air-inlet
connections vary between
models, see Figure 4-3.
(model Tft60-110 shown)
Exhaust
Inlet
