RM/RA SERIES OWNER’S MANUAL
NUVU® MENOMINEE, MICHIGAN 49858
(906) 863-4401 SALES FAX (906) 863-5889 • SERVICE FAX (906) 863-6322 page 17
RM SERIES COMPONENTS:
11 Contactor ……………………………………………………….. .................... 66-2017
12 Temperature Control ......................................................................................... 252-5008
Control Knob .......................................................................................... 252-2003
13 Temperature Control Sensor ............................................................................. 252-3001
14 Temperature Control Indicator Light 230V ………………………… ............. 50-0030
15 Timer, 60-Minute 230V 50hz …………………………………… ................ 252-1020
Timer, 60-Minute 230V 60hz …………………………………… ................ 252-1019
Timer Knob .............................................................................................. 253-2002
16 Buzzer Alarm 240V ……………………………………………….................... 66-1113
17 Motor Speed Switch ........................................................................................... 50-1392
RA SERIES COMPONENTS:
18 Solid state relay………………………………………………….. .................... 66-2003
19 Power supply ........................................................................................................ 50-0947
20 Temperature control sensor .................................................................................. 66-1038
21 PLC .................................................................................................................... 66-1152
22 Touch screen ......................................................................................................... 66-1148
INTERIOR COMPONENTS:
27 Blower Wheel ..................................................................................................... 50-0408
28 Oven Element Cover ........................................................................................... 07-0242
DOOR COMPONENTS:
29 Latch .................................................................................................................... 50-1360
30 Catch .................................................................................................................... 50-0421
31 Door Gasket .................................................................................................. 700-0083-A
GENERAL EXTERIOR COMPONENTS:
32 Side Access Panel ............................................................................................... 07-0222
33 Outside Top:
Solid back ................................................................................................. 07-0224
Pass Through .............................................................................................. 07-0223
34 6” adjustable leg .................................................................................................. 50-0555
35 Water Inlet Fitting ............................................................................................... 31-0058
INTERNAL STEAM OPTION COMPONENTS, RM series:
36 Steam Switch ...................................................................................................... 50-1356
37 Water Supply Solenoid Valve 230V ……………… ………………… .............. 50-0307
38 Water Injection Nozzle ....................................................................................... 31-0033
39 Steam Injection Timer 230V ………………… …………………… .................. 50-0691
