Bolt D
Bolt D
Bolt A
Nut B
Nut B
Nut B
How to fix the entirely
assembled frame.
Fix the frame by fastening bolt
D (2 pieces) and nut B
(2 pieces) after setting the main
base frame, main frame and sub
frame as shown in the picture.
How to fix the entire bolts
again.
Fasten the entire bolts and nuts
tightly once again after the
assembly is completed.
Completed appearance
How to assemble the
remote controller holder.
Fasten bolt A (1 piece) and
nut B (1 piece) after inserting
the remote control holder into
the instructed ‘S’ position.
L-wrench
T-1
How to Assemble the Product Frame
NM-5000
Product Installation and Preparations
To Next Page
