How$to$Assemble$the$Product$Frame
NM#5000P
How$to$Assemble$the$Product$Frame
Screw$No.$4
Screw$No.$7
Screw$No.$8
Screw$No.16
Screw$No.16
Connect$frame$legs$to$a$
handle$cover
Arrange'2'pieces'of'frame'legs,'1'
piece'of'pipe'connector'and'1'piece'of'
handle'cover'as'shown'in'the'picture.
Fix'the'handle'cover'with'3'pieces'of'
Screw'No.'4'as'shown'in'the'picture.
Connect$a$molding$frame$
with$floral$pattern
Insert'the'frame'leg,'assembled'in'
the'previous'step,'onto'a'piece'of'a'
molding'frame'with'floral'pattern.
Fix$a$molding$frame$with$no$
pattern
Cover'a'molding'frame'with'no'
pattern'and'fix'it'with'5'pieces'of'
Screw'No.'8'as'shown'in'the'picture.
Fix'the'assembled'frame'leg'with'2'
pieces'of'Screw'No.'7.
Fix$the$main$base$frame
Fix'the'main'base'frame'with'4'
pieces'of'Screw'No.'16'to'the'
assembled'frame'leg'as'shown'in'the'
picture.
Insert$both$the$center$
support$and$leg$support
Insert'a'piece'of'center'support'into'
the'assembled'molding'frame'with'
no'pattern'as'shown'in'the'picture.
Fix'2'pieces'of'leg'supports'with'2'
pieces'of'Screw'No.'13'to'the'assembled'
frame'leg'as'shown'in'the'picture.
Fix$the$assembled$frame$leg
Put'the'assembled'frame'leg'on'the'main'
assembly'as'shown'in'the'picture,'and'
then'put'on'the'center'support'exactly'to'
the'hole'on'the'molding'frame.
Fix'the'assembled'frame'leg'with'4'
pieces'of'Screw'No.'16'as'shown'in'
the'picture,'and'then'fix'the'center'
support'with'2'pieces'of'Screw'No.'12.
Fit$a$foot$cover$respectively$into$the$end$of$
a$frame$leg.
Repeat$the$above$steps$to$assemble$one$
more$frame$leg.
Insert$2$pieces$of$hole$covers$to$the$outside$of$
the$assembled$molding$frame$with$floral$pattern.
Screw$No.13
Screw$No.12
ⴘ
ⴙ
ⴙ
ⴘ
ⴙ
Leg$support
Center$support
Hole$cover
