List of Errors
en-938821/2 B - 9
B
B.10 Dynamic Operators in C
Error No. Meaning of the error
400 Loading dyn. ops in C: The size of user code is too big
401 Loading dyn. ops in C: Format error
402 Loading dyn. ops in C: Checksum error
403 The system has insufficient memory for dyn. ops in C
404 Loading dyn. ops in C: Open error
405 Loading dyn. ops in C: Read error
406 Loading dyn. ops in C: Close error
407 Loading dyn. ops in C:The directory is empty
410 Dyn. ops in C: Number of parameters passed doesn’t tally
411 Dyn. ops in C: USER ERROR from INIT: negative return
413 Unrecognised dyn. ops in C
414 Dyn. ops in C without MAIN
420 Dyn. ops in C: USER ERROR from the QUIT function
421 Dyn. ops in C: USER ERROR from the QUIT function: negative return
423 Dyn. ops in C: Range of function in C not from [0..100]
B.11 Spline Curve Interpolation Errors
Error No. Meaning of the error
600 Curve number zero
601 N.. N.. must be programmed
602 No axes programmed in the first block of the contour
603 Curve slope undefined
604 Less than three blocks in the profile
605 Curve number unknown
B.12 Errors in Numaform
Error No. Meaning of the error
700 Options missing
701 S.. missing at beginning of curve
702 Number of S.. different in T1 & T2
703 Minimum 2 occurrences of S in T1
704 Undefined section (in T3)
705 Plane switching outside S mark
706 Spindle stopped
707 Invalid E= function
708 E=1 or E=2: Section positioning error
709 T1 & T2 can’t have any points in common
710 P, Q must be positive
711 S different in T1 & T2
712 Undetermined tool position
713 Error: S=0 or T>3
730 F= less than or equal to zero
731 Intersection of concentric circles
732 Intersection of parallel lines
733 Limit cannot be a horizontal plane
740 F = error
