B - 8 en-938821/2
B.8 Errors in Pocket Cycles
Error No. Meaning of the error
260 Working memory busy
261 Programme number too high
262 NU number not among those authorised
263 Execution impossible - Test or Graphic mode mandatory after first load or after editing
264 No dimension programmed in the contouring plane or dimension outside the plane
265 First positioning block missing; contour definition must begin with G0 or G1
266 Not enough memory
267 Character not allowed in pocket syntax
268 Pocket programming block incomplete or containing illegal data
269 Contour block incomplete / Positioning block missing before pocket definition
270 Pocket definition partly or completely missing
271 Tool orientation not perpendicular to the contouring plane
272 Real tool not compatible with pocket technological data
273 Change of contouring plane between pocket definition and machining
274 Two nested pocket definitions
275 NU0 programmed with G59
276 Zero pocket depth
277 Pocket definition start point or end point coordinates incomplete
278 The spindle rotation direction is incompatible with the one required in the pocket definition
279 G function not allowed in a pocket programming block
280 First contour block incomplete
281 Discontinuity in one of the contours described
282 Pocket definition parameter error(s)
283 The external contour must be unique and must exist
284 Error in contour definition
285 Too many contours
286 Pass setting excessive with respect to the tool diameter
287 Pass setting insufficient with respect to the dimensions
288 Finishing infeed in an acute angle or an unroughed area: change the infeed point
289 Tool diameter excessive
290 Internal error
291 Finishing infeed outside the contour
292 Double positioning at the start of the contour
293 Roughing end point present during facing
B.9 Axes Not Identified on the Bus
Error No. Meaning of the error
300 to 309 ∗ Axis 0 to 9 declared in P2 but not detected on the bus
310 to 319 ∗ Axis 10 to 19 declared in P2 but not detected on the bus
320 to 329 ∗ Axis 20 to 29 declared in P2 but not detected on the bus
330 and 331 ∗ Axis 30 and 31 declared in P2 but not detected on the bus
∗ Machine error. Caution: For this type of error, a CNC reset causes a general reset (CNC reset + PLC reset)
