C - 26 en-938821/2
C.2.4.2 Numerical Control / Printer Connection
PRINTER NUM CNC
Sub.D connector Sub.D connector
25 male contacts 25 male contacts
or DIN 6 male contacts
DCD
RD TD
GND GND
DTR CTS
Signal DIN 6-contact plug 25-contact Sub.D
(EPSON EX800)
RD 3 3
GND 5 7
DTR 2 20
C.2.4.3 Setting up the Link for Printing
Actions
Connect the printer to a serial line of the CNC.
Configure the printer: RS 232 serial link, 9600 bauds, 7 data bits and 1 parity bit.
Carry out the printing procedure (See printer documentation).
C.2.4.4 Setting up the Link for Hard Copy
Actions
Connect the printer to a serial line of the CNC.
Configure the printer: RS 232 serial link, 9600 bauds, 8 data bits and no parity bit.
Carry out the printing procedure (See printer documentation).
