Numark CDN-34S - Specifications

CDN-34S
- The Leader in DJ Technology
©1999 Numark Industries - 19 - http://www.numark.com
SPECIFICATIONS
TECHNICAL
Quantization 16-bit
linear/channel, 3 beam laser
Oversampling rate 8 times
Frequency response 20Hz-20KHz
Channel separation 86dB
T.H.D. + NOISE 0.01%
S/N ratio (IHF-A) 94dB
Output level 2.0Vrms
Short access time
(Play next track) less than 1.7sec
Long access time
(Track 1 ->Track 20) less than 3sec
Instant start less than .015 sec
Pitch control range +/-12%
Pitch bend +/-16%
Digital Output type 2, form 1,
S/PDIF (Sony/Phillips Digital Interface Format)
CONTROL UNIT
132mm
74mm
60mm
482mm
GENERAL
Dimensions:
Main Unit: 482 (W) x 88.8 (H) x 264 (D) mm
(without feet) 19 (W) x 3.5 (H) x 10 3/8 (D) inches
Control Unit: 482 (W) x 132 (H) x 74 (D) mm
(without feet) 19 (W) x 5 1/4 (H) x 2 7/8 (D) inches
Weight: Player Unit: 5 Kgs., 11 lbs.
Control Unit: 2 Kgs., 4.4 lbs.
Power Supply: 115/230V AC, 50/60Hz
Power Consumption: 25W
TRANSPORT UNIT
482mm
264mm
88.8mm
