Numatic International Spare Parts
Model No:TTB455 Base/Deck Assy
POS: PAR T NO: DESCRIPTION: COMMENTS:
1 229368 BASE MOULDING
2 320295 24 VO LT MOTOR
3 220806 MOTOR CONTROL PCB
4 219569 No8 X 1/2" LONG POZI PAN SCREW
5 219075 M4 FULLNUT
6 219072 M5 FULLNUT
7 219015 M4 SHAKEPROOF WASHER
8 219016 M5 SHAKEPROOF WASHER
9 390860 AXLE TUBE
10 303247 100MM DIAMETER WHEEL
11 204021 12.7MM HUB CAP
12 229182 DRIVE SHAFT
13 219523 GROOVED PIN
14 230207 CHUCK
15 230048 26MM EXTERNAL CIRCLIP
16 229364 RUBBER BUFFER
17 229369 TOP COVER MOULDING
18 229365 FIXING CLIP
19 219686 M4 X 20MM LONG POZI PAN STAINLESS STEEL SCREW
20 219688 M4 FORM A STAINLESS STEEL WASHER
21 219687 M4 NYLON INSERT STAINLESS STEEL NUT
22 206013 BUFFER WHEEL PIN
23 219644 M5 FORM G WASHER
24 219572 M5 X 16MM LONG STAINLESS STEEL COUNTERSUNK SCREW
25 219571 M5 X 20MM LONG POZI HEAD STAINLESS STEEL SCREW
26 229361 LOCKING PIN
27 219151 13MM EXTERNAL CIRCIP
28 390858 32MM LONG SPACER
29 219649 M10 NYLON INSERT NUT
30 219449 M10 FORM A WASHER
31 219570 M10 X 70MM LONG BOLT
32 219568 No8 X 3/4" LONG PLASTITE SCREW
33 303463 SOLENOID MOUNTING PLAT E
34 220378 SOLENOID VAL V E LEAD ASSEMBLY + MPM CONNECTOR
35 220379 24V DC SOLENOID VAL E
36 202081 MPM CONNECTOR GASKET
37 219251 M3 SCREW
38 219622 M4 X 35MM LONG POZI PAN MACHINE SCREW
39 303248 900MM LONG SILICON TUBE
40 320725 MOTOR LEAD ASSEMBLY
41 219007 M6 FORM B WASHER
42 219008 M6 FORM G WASHER
43 219315 M6 X 50MM LONG BOLT
44 219606 BRACKET SPACER
45 227008 CABLE CLAMP
46 219107 No6 X 5/8" LONG PLASTITE SCREW
