4002 non-addressable control and indicating equipment
User Manual
8
32-0015-r06_2018-03
© 2015 ~ 2018 Ambest Electronics (Ningbo) Co Ltd. All rights reserved.
All specifications and other information shown were current at the date of publication and subject to change without notice.
3.6. Disabled Condition
A function may be disabled. The Disabled Condition is used to inhibit:
Events from within the Zone (eg a detector alarm) being actioned by the control and indicating equipment.
Actions initiated by the control and indicating equipment from occurring within the Zone (eg activation of
an alarm device)
Signals being sent to auxiliary outputs.
3.6.1. Detection Zone Disablement
To disable a detection zone, take the following actions:
1) Enter Access Level 2.
2) Press the SELECTED ZONES button. The SELECTED ZONES LED will flash and the ACKNOWLEDGE
LED will flash.
3) Press the ACKNOWLEDGE button. SELECTED ZONES LED will be on and the ACKNOWLEDGE LED
will flash.
4) Press the SILENCE/ACTIVATE ALARMS button to scroll through the detection zones 1 ~ 8. As the button
is pressed, the selected zone TEST FAULT DISABLED yellow LED will be on.
5) Once the desired Zone LED indicator is on, confirm the selection by pressing the ACKNOWLEDGE button.
The FIRE LED in the selected Zone will be on steady. The ACKNOWLEDGE LED will continue to flash.
This gives the user an option to re-enable the selected Zone.
6) To exit the disablement selection press the SELECTED ZONES button. The SELECTED ZONES LED will
be off. The control and indicating equipment will remain in Access Level 2.
3.6.2. Delays Active/Inactive
To inhibit pre-configured delays to the Alarm Condition, take the following actions:
1) When the Alarm Condition is not present, enter Access Level 2.
2) Press the DELAYS ACTIVE button. The DELAYS ACTIVE LED will flash, and the ACKNOWLEDGE LED
will flash.
3) Confirm the selection by pressing the ACK button. The ACKNOWLEDGE LED will be off and the DELAYS
ACTIVE LED will be off.
3.6.3. Alarm Zone Disablement
To disable alarm devices, take the following actions:
1) Enter Access Level 2.
2) Press the ALARM ZONES button. The ALARM ZONES LED will flash and the ACKNOWLEDGE LED will
flash.
3) Confirm the action by pressing the ACKNOWLEDGE button. The ACKNOWLEDGE LED will be off. The
ALARM ZONES LED will be on.
4) To exit the disablement selection press the ALARM ZONES button. The ALARM ZONES LED will flash
and the ACKNOWLEDGE LED will flash.
5) Confirm the action by pressing the ACKNOWLEDGE button. The ACKNOWLEDGE LED will be off. The
ALARM ZONES LED will be off. The control and indicating equipment will remain in Access Level 2.
In the Alarm Condition, delays can be disabled at Access Level 1.
If there is an alarm waiting to be processed when the delays are disabled, the control
and indicating equipment will immediately enter the Alarm Condition.
For the Delays Active/Inactive function, the zones must first be configured to enable
the delay at Access Level 3.
