4002 non-addressable control and indicating equipment
User Manual
9
32-0015-r07_2018-03
© 2015 ~ 2018 Ambest Electronics (Ningbo) Co Ltd. All rights reserved.
All specifications and other information shown were current at the date of publication and subject to change without notice.
3.6.4. Auxiliary Outputs Disablement
To disable the auxiliary outputs, take the following actions:
1) Enter Access Level 2.
2) Press the AUXILIARY OUTPUTS button. The AUXILIARY OUTPUTS LED will flash and the
ACKNOWLEDGE LED will flash.
3) Confirm the action by pressing the ACKNOWLEDGE button. The ACKNOWLEDGE LED will be off. The
AUXILIARY OUTPUTS LED will be on.
4) To exit the disablement selection press the AUXILIARY OUTPUTS button. The AUXILIARY OUTPUTS
LED will flash and the ACKNOWLEDGE LED will flash.
5) Confirm the action by pressing the ACKNOWLEDGE button. The ACKNOWLEDGE LED will be off. The
AUXILIARY OUTPUTS LED will be off. The control and indicating equipment will remain in Access Level 2.
3.6.5. Enable Functions
To re-enable a disabled function, follow the steps above and note that the relevant disablement LED indicator
is off.
3.7. Test Condition
Tests can be conducted by a single person. To enter the Test Condition and undertake tests of the 4002 and
connected devices, follow these steps:
3.7.1. Indicator Test
1) Enter Access Level 1 or Access Level 2.
2) Press the INDICATOR TEST button. The internal sounder will operate. All LED indicators on the control
and indicating equipment and any connected remote display will be illuminate until the INDICATOR TEST
button is released.
3.7.2. Device Test
1) Enter Access Level 3.
2) Press INDICATOR TEST button. The TEST LED will flash and the ACKNOWLEDGE LED will flash.
3) Press the ACKNOWLEDGE button. The ACKNOWLEDGE LED will be off. The TEST LED in the STATUS
section and the TEST FAULT DISABLED LEDs in the ZONES section will be on.
4) Test a device connected to each alarm zone circuit. Upon activation of the device:
the FIRE LED will illuminate for 5 s;
the Detector Zone indicator will illuminate for 5 s;
any connected remote display Detection Zone indicator will illuminate for 5 s; and
the internal sounder, and alarm devices will operate for 1 s.
Zones will automatically reset after 10 s.
5) At the completion of the tests and to exit the Test Condition, press the INDICATOR TEST button. The TEST
LED will flash and the ACKNOWLEDGE LED will flash.
6) Press the ACKNOWLEDGE button. The ACKNOWLEDGE LED will be off. The TEST LED in the STATUS
section and the TEST FAULT DISABLED LEDs in the ZONES section will be off. The control and indicating
equipment will remain in Access Level 3.
